【 Application Fields 】Online debugging, offline testing, aging testing, functional verification, etc. of DC charging pile products.

This series of DC charging pile testing system exchanges information with electric vehicle DC charging piles through an internal BMS simulator, achieving real-time simulation of the battery charging process. When the charging gun of the DC charger is connected to the interface of the testing equipment, the testing equipment completes connection detection, charging handshake, configuration, and charging according to the national standard for communication protocol between non vehicle chargers and BMS (GBT27930-2015), and detects charging voltage and current, auxiliary power supply voltage and current

 I Highlight Features

? Multiple standard DC charging pile simulation interfaces can be configured

? Multiple power options available, maximum power of 500KW

Working voltage: 60~1000V, working current: up to 960A

Operating modes such as constant current (CC) and constant voltage (CV)

Parallel control of multiple machines, capable of synchronously executing multiple sets of loads in parallel and pulling loads

Efficient PWM modulation algorithm effectively reduces switching losses

? Built in isolation transformer, with a maximum conversion efficiency of 94%

BMS simulation, communication consistency, control guidance, and battery voltage simulation functions

High precision measurement of voltage, current, and power

Input/output overvoltage/undervoltage protection function

? Multi functional remote control test

Short circuit and reverse connection protection

Equipped with RS232 communication interface, RS485/GPIB/LAN/CAN (optional)
