I Highlight Features

?Chinese and English operation interface

?7-inch 800X480 color TFTLCD display with a testing frequency of 20-200MHz and a testing accuracy of up to 0.05%

?LCR testing speed up to 120 times/second, fast DC measurement up to 80 times/second

?USB directly saves test data, Excel document displays test values

?No need to flip pages. Test results can be displayed on one page. Each measurement parameter can be set to different frequencies and voltages. Multiple sets of primary page settings with parameter copying function

?Standard Handler and RS232 interface (GPIB optional) flexible leakage inductance short-circuit pin setting: up to 20 types of leakage inductance classification

?Resolve errors caused by wiring different testing fixtures: Each winding group can be opened and short

?Equipped with defective cylinder locking function: effectively preventing defective products from flowing out due to human error

The T3000 series transformer comprehensive tester is a transformer testing system that integrates high speed, high precision, and high performance. Can meet the quality assurance, incoming inspection, and laboratory measurement requirements of the production line, and provide solutions for automated multi piece testing: can provide independent signal output for 5 sets of primary page good and defective products
